White Painted Ceiling Cable Hanging System Mounting Brass Material Ceiling Coupler

Yingwei Lighting Accessory Co.,Ltd.
Trust Seal
Verified Supplier
Credit Check
Supplier Assessment

White Painted Ceiling Cable Hanging System Mounting Brass Material Ceiling Coupler

Brand Name : YW

Model Number : YW-86260

Place of Origin : Dongguan,China

MOQ : 1,000pcs

Price : Negotiable

Payment Terms : T/T, Western Union

Supply Ability : 100,000pcs/Month

Delivery Time : 10-15 Work Days

Packaging Details : Export Carton-35*25*18cm

Material : Brass

Finish Color : White/Customized

Thread : NO

Size : Φ15*31mm

Thread Size : M6

Others : OEM/ODM

Contact Now

White Painted Ceiling Cable Hanging System Mounting , Brass Material Ceiling Coupler

This ceiling coupler is made from brass material,painted in White color.

White Painted Ceiling Cable Hanging System Mounting Brass Material Ceiling Coupler

ITEM NAME MATERIAL MEASUREMENT
Φ15MM CEILING ATTACHMENT BRASS WITH PLATED IN WHITE

Φ0.59'' * 1.22''

Φ15*31MM

Description

1. Item Name : Φ15mm Chrome Finish Ceiling Attachment

2. Material : Brass/Copper

3. Size : Φ15*31mm

4. Finishing Color : White;Or Customize

5. Application:Perfect for the Hanging Graphic Displays,as well as Suspend

Signage,Lighting Systems ,Suspended Fixtures and so on.

6. Safe Working Load;30KG(Fore reference only)

Cable coupler be fixed to the hard ceiling by screw,non-adjustable.

Many Ceiling Attachment styles allow you to attach anything you want to hang,working with

different cable gripper styles allow for limitless hanging installation options.

This attachment provides a firm anchor for the suspension system wire to fixed onto the ceiling.

In the standard configuration, the attachment barrel is screwed onto the ceiling, and the suspension

wire is threaded through the collar-locking nut, with the nipple at the end of the suspension wire

locating into the collar, which is then screwed into the barrel.

Confused about how to select your hanging system?


1. Choose a Suspension Point
Your system can be ceiling or wall mounted, with applications

hanging freely or tensioned between two fixed points;


2. Pick a Cable
Our stainless steel aircraft cable comes in several diameters

and lengths ranging from 1.0mm~3.0mm;


3. Select a Gripper
A range of designs and options, all with self gripping technology,

offer a secure and elegant solution for any fine art installation.

4. Select a Ceiling Attachment

Many different types,for har ceiling and slop ceiling,

To fix the cables to ceilings, walls or floors.

Quality Control

As all manufacturers and installers know, suspending objects safely

over people’s heads is their first and most critical responsibility.

Safety is our number one concern. Each and every gripper is a

precision-built machine.

Materials & Finishes


Ceiling Attachments are made of nickel / Chrome-plated brass with a few exceptions.

Internal mechanisms are comprised of brass and stainless steel.

Satin-chromed and other finishes are available upon request.

Thread Sizes


Most Ceiling Attachment and Cable Grippers have either internal or

external threads to attach them to the object being suspended.

IMPORTANT: It is essential to check that the top ceiling fixings are strong enough to

take the weight of the items being displayed, while allowing for the tension in the cables.

Affix ceiling attachment to ceiling:

- for wooden ceilings use a wood screw.

- for cavity ceilings use a spring toggle bolt.

- for solid ceilings use a rawl plug and screw.
